756 摩 擦 学 学 报 第 41 卷
(a) 1 050 MPa (b) 1 150 MPa (c) 1 250 MPa
5 μm 5 μm 5 μm
Iron bcc (old) Iron fcc Iron bcc (old) Iron fcc Iron bcc (old) Iron fcc
5
Fig. 10 Phase map of BF and RA phases at a distance of 10 μm from the surface during 5×10 cycles of different contact stresses
5
图 10 不同接触应力运行5×10 周次距表层10 μm处BF和RA相分布图
素达到极限水平[见图10(c)]，所以磨损量与1 150 MPa 参 考 文 献
时相比并没有显著增加.
[ 1 ] Hasan S M, Ghosh M, Chakrabarti D, et al. Development of
3.3 硬化机理 continuously cooled low-carbon, low-alloy, high strength carbide-
FCB车轮钢组织硬化是1个复杂的过程，是多种 free bainitic rail steels[J]. Materials Science and Engineering:A,
因素共同作用的结果. 试样运行高周次时[见图8(b)]， 2020, 771: 138590. doi: 10.1016/j.msea.2019.138590.
[ 2 ] Marinelli M C, Balbi M, Krupp U. Influence of plastic deformation
试样磨损表面硬化效果显著. 在1 150和1 250 MPa时，
in fatigue crack behavior in bainitic steel[J]. International Journal of
表面硬度相差不大，但却明显高于1 050 MPa条件下
Fatigue, 2021, 143: 106014. doi: 10.1016/j.ijfatigue.2020.106014.
的硬度. 这是由于在1 150 MPa条件下，表层晶粒已经 [ 3 ] Neog S P, Bakshi S D, Das S. Microstructural evolution of novel
细化为超细等轴晶，晶粒细小，晶界增多，细晶强化作 continuously cooled carbide free bainitic steel during sliding
用明显；此外经公式(1)计算得到原始BF板条中位错 wear[J]. Wear, 2020, 456-457: 203359. doi: 10.1016/j.wear.2020.
−2
10
密度为4.91×10 m ，组织在塑性变形的过程中位错 203359.
[ 4 ] Liu J P, Li Y Q, Jin J Y, et al. Effect of processing techniques on
密度增加6个数量级，位错强化机制同样影响组织的
microstructure and mechanical properties of carbide-free bainitic rail
硬度，因此接触应力为1 150 MPa时表层硬度明显升
steels[J]. Materials Today Communications, 2020, 25: 101531. doi:
高. 在接触应力为1 250 MPa时，由于晶粒细化和位错 10.1016/j.mtcomm.2020.101531.
强化的限度，硬化速率减慢. [ 5 ] Moghaddam P V, Hardell J, Vuorinen E, et al. Dry sliding wear of
nanostructured carbide-free bainitic steels? Effect of oxidation-
4 结论 dominated wear[J]. Wear, 2020, 454-455: 203317. doi: 10.1016/j.wear.
2020.203317.
5
a. 在运行2×10 周次时，不同接触应力下运行表面
[ 6 ] Tan Z, An B, Gao G, et al. Analysis of softening zone on the surface
均以黏着磨损为主，对磨损量的影响并不明显. 运行
of 20Mn2SiCrMo Bainitic railway switch[J]. Engineering Failure
5
5×10 周次时，运行表面均以疲劳磨损为主，当接触应 Analysis, 2015, 47: 111–116. doi: 10.1016/j.engfailanal.2014.10.013.
力增至1 150 MPa时，磨损量增幅显著，继续增加接触 [ 7 ] Moghaddam P V, Hardell J, Vuorinen E, et al. Effect of retained
应力，磨损量增幅不大. austenite on adhesion-dominated wear of nanostructured carbide-
free bainitic steel[J]. Tribology International, 2020, 150: 106348.
5
b. 在运行5×10 周次，接触应力为1 050 MPa时，板
doi: 10.1016/j.triboint.2020.106348.
条BF发生明显变形；接触应力增大为1 150 MPa时，贝
[ 8 ] Li S, Zhu R, Karaman I, et al. Development of a kinetic model for
氏体铁素体晶粒细化成平均晶粒尺寸约为0.12 μm的
bainitic isothermal transformation in transformation-induced
超细晶. 继续增加接触应力，组织没有明显变化. plasticity steels[J]. Acta Materialia, 2013, 61(8): 2884–2894. doi:
c. 在塑性变形的过程中，BF中位错逐渐增值、累 10.1016/j.actamat.2013.01.032.
积形成小角度晶界，随着变形的加剧，大角度晶界数 [ 9 ] Lucas J P, Gerberich W W. Cyclic strain hardening of polygonal and
acicular ferrite/bainite microstructures in microalloyed steels in the
量增加，增大接触应力造成次表面位错密度降低.
temperature range-150 ℃ to 27 ℃[J]. International Journal of
d. 在一定接触应力范围内，接触应力大小会影响
Fatigue, 1985, 7(1): 31–38. doi: 10.1016/0142-1123(85)90005-2.
贝氏体车轮钢的表面硬度. 接触应力增加使贝氏体车 [10] Leiro A, Vuorinen E, Sundin K G, et al. Wear of nano-structured
轮钢的表面硬度增高，硬化层深度增大. carbide-free bainitic steels under dry rolling-sliding conditions[J].
