图 7 P 1 和 P 2 处模拟的速度剖面 图 8 训练点上速度代理模型和数值模拟的计算结果比较
Fig. 7 Numerical simulated velocity profiles Fig. 8 Results calculated by the speed surrogate model at the
training points and the numerical simulation result
at P 1 and P 2

表 2 训练点上速度剖面代理模型计算的相对误差
Table 2 Relative errors of velocity surrogate model calculation at training points

相对误差/% 相对误差/%
h/mm h/mm
P 1 P 2 P 1 P 2
0 0.003 4 0.004 0 3 0.005 7 0.001 4
1 0.007 8 0.009 4 4 0.002 7 0.009 4
2 0.006 3 0.003 6 5 0.003 5 0.006 7
