陈越中等:背栅型纳米真空沟道晶体管阵列的电学特性及其高频小信号等效电路模型研究                                       301


                  field emission devices-Nano electrode geometries compari-  electronics[J]. Nano Letters,2018,18(12):7478−7484.
                  son  of  performance  and  stability[J].  Small, 2022, 18(47):  [21]   WANG  X, ZHENG  C, XUE  T, et  al.  Nanoscale  vacuum
                  2203234.                                          field emission triode with a double gate structure[J]. IEEE
              [16]   SHIH P C,PEROZEK J,AKINWANDE A I,et al. Anode-  Electron Device Letters,2022,43(2):292−295.
                  integrated  GaN  field  emitter  arrays  for  compact  vacuum  [22]   ZHANG Y,ZHANG G,ZHAN F,et al. Planar nanoscale
                  transistors[J]. IEEE Electron Device Letters,2023,44(11):  vacuum channel transistors based on resistive switching[J].
                  1895−1898.                                        Nanotechnology,2024,35(21):215205.
              [17]   WEI  Y, CHEN  F, HUANG  R, et  al.  Fast  response  GaN
                                                                [23]   XU J,QIN Y,SHI Y,et al. Design and circuit simulation of
                  nanoscale air channel diodes with highly stable 10 mA output
                                                                    nanoscale vacuum channel transistors[J]. Nanoscale Advance,
                  current toward wafer-scale fabrication[J]. Advanced Science,
                                                                    2020,2(8):3582−3587.
                  2023,10(17):2206385.
                                                                [24]   FOWLER  R  H, NORDHEIM  L.  Electron  emission  in  in-
              [18]   HSU  S  H, KANG  W  P, RAINA  S, et  al.  Nanodiamond
                                                                    tense electric fields [J]. 1928,119(781):173-181.
                  vacuum  field  emission  device  with  gate  modulated  triode
                                                                [25]   LENZLINGER M,SNOW E H. Fowler-Nordheim tunneling
                  characteristics[J]. Applied Physics Letters,2013,102(20):
                                                                    into  thermally  grown  SiO 2 [J].  Journal  of  Applied  Physics,
                  203105.
                                                                    1969,40(1):278−283.
              [19]   FAN L,BI J,XI K,et al. Sub-10-nm air channel field emis-
                                                                [26]   ELLIS R K. Fowler-Nordheim emission from non-planar sur-
                  sion device with ultra-low operating voltage[J]. IEEE Elec-
                                                                    faces[J]. IEEE Electron Device Letters,1982,3(11):330−
                  tron Device Lett,2021,42(9):1390−1393.
                                                                    332.
              [20]   NIRANTAR S,AHMED T,REN G,et al. Metal–air tran-
                  sistors:semiconductor-free field-emission air-channel nano-          (责任编辑:郭 云)






































              引文信息:陈越中,赵浩东,俞道龙,等. 背栅型纳米真空沟道晶体管阵列的电学特性及其高频小信号等效电路模型研究[J].
                      真空与低温,2025,31(3):292−301.
                      CHEN Y Z,ZHAO H D,YU D L,et al. Electrical characteristics and high-frequency small-signal equivalent circuit model
                      of back-gated nanoscale vacuum channel transistor arrays[J]. Vacuum and Cryogenics,2025,31(3):292−301.
