第 4 期 吴杰, 等: 干气密封推环用弹簧蓄能密封圈工作特性研究 541

2 000 [ 3 ] Chen Yuan, Jiang Jinbo, Peng Xudong, et al. Dynamic performance
P=6 MPa 1 395 N
1 600 P=9 MPa of dry gas seals and analysis of interactions among its influencing
P=12 MPa 1 084 N 1 120 N
1 200 factors[J]. Tribology, 2019, 39(3): 269–278 (in Chinese) [陈源, 江
884 N
锦波, 彭旭东, 等. 干气密封力学系统动态性能及其影响因素间的
800 912 N 交互作用分析[J]. 摩擦学学报, 2019, 39(3): 269–278]. doi: 10.16078/
Friction/N 400 713 N j.tribology.2018144.

0
0 10 20 30 40 50 60 [ 4 ] Bai Shaoxian, Wei Jia, Zhu Delei, et al. Thermoelastohydrodynamic
−400 Displacement/μm gas lubrication of T-Groove face seals: stability of sealing film[J].
−800 Tribology, 2019, 39(2): 131–139 (in Chinese) [白少先, 魏佳, 朱得
磊, 等. T型槽端面密封气膜热弹流润滑动态稳定性[J]. 摩擦学学
−1 200

报, 2019, 39(2): 131–139]. doi: 10.16078/j.tribology.2018073.
Fig. 18 Variation of friction of C-ring without a boss under
[ 5 ] Zheng Jinpeng, Shen Mingxue, Meng Xiangkai, et al. Fretting
different medium pressure with displacement of
push ring (ε=5%) characteristics of the rubber o-ring for a mechanical seal[J]. Journal
图 18 无台C形圈不同介质压力下摩擦力随推环 of Shanghai Jiaotong University, 2014, 48(6): 856–862 (in Chinese)
位移的变化(ε=5%) [郑金鹏, 沈明学, 孟祥铠, 等. 机械密封用O形橡胶密封圈微动特
性[J]. 上海交通大学学报, 2014, 48(6): 856–862]. doi: 10.16183/
推环与夹套圈接触面之间的接触压力增大. 而随着介 j.cnki.jsjtu.2014.06.022.
质压力增大(6、9和12 MPa)，分离距离将大幅增长，分 [ 6 ] Wu Qiong, Suo Shuangfu, Liu Xiangfeng, et al. Static sealing and
别达到12、25和35 μm. pseudo-sealing characteristics of nitrile rubber O-ring[J].

Lubrication Engineering, 2012, 37(11): 5–11 (in Chinese) [吴琼, 索
5 结论 双富, 刘向锋, 等. 丁腈橡胶O形圈的静密封及微动密封特性[J].

润滑与密封, 2012, 37(11): 5–11]. doi: 10.3969/j.issn.0254-0150.2012.
a. 介质压力对C形圈产生了二次压缩，使弹簧蓄
11.002.
能密封圈在较小的预压缩率下也可以实现密封. 相比
[ 7 ] Liao C J, Suo S F, Wang Y M, et al. Study on stick-slip friction of
于无台结构，有台结构的接触宽度略大，峰值接触压
reciprocating O-ring using acoustic emission techniques[J].
力略小. Tribology Transactions, 2012, 55(1): 43–51. doi: 10.1080/10402004.
b. 推环与C形圈之间的摩擦力是不可忽略的. 介 2011.626145.
质压力越大，弹簧蓄能密封圈与推环间的摩擦力越 [ 8 ] Lai T, Kay P. Breakaway frictions of dynamic o-rings in mechanical
大，当ε=5%，P=9 MPa，有台和无台两种密封圈的最大 seals[J]. Lubrication Engineering, 1993, 49(5): 349–356.
[ 9 ] Dhanumalayan E, Joshi G M. Performance properties and
摩擦力分别可达1 215和1 218 N.
applications of polytetrafluoroethylene (PTFE)-a review[J].
c. 无台、有台弹簧蓄能密封圈具有不同的摩擦特
Advanced Composites and Hybrid Materials, 2018, 1(2): 247–268.
性，相较于无台结构，有台C形圈能够改善补偿环组件
doi: 10.1007/s42114-018-0023-8.
的浮动性和追随性. 推环沿Z方向微动时，有台C形圈 [10] Sui Hai, Pohl H, Schomburg U, et al. Wear and friction of PTFE
的分离距离更大，不易引起“突跳”. 推环沿-Z方向微 seals[J]. Wear, 1999, 224(2): 175–182. doi: 10.1016/s0043-
动时，有台C形圈的分离距离BD很短，摩擦力也更小， 1648(98)00306-8.
可以克服静环组件回程悬挂的问题. [11] Jia Xiaohong, Li Kun. A research on 2-D axisymmetric finite
element model for spring energized seal ring[J]. Lubrication
