第 41 卷     第 3 期                        摩  擦  学  学  报                                  Vol 41   No 3
            2021  年 5  月                                 Tribology                                   May, 2021


            DOI: 10.16078/j.tribology.2020117



                         仿生猪笼草结构的水润滑轴承摩擦学

                                         性能有限元分析研究




                                                           1,2*
                                                                     1,2
                                                1,2
                                         李云凯 , 王优强 , 菅光霄 , 罗  恒               1,2
                                      (1. 青岛理工大学 机械与汽车工程学院，山东 青岛 266520;
                                   2. 工业流体节能与污染控制教育部重点实验室，山东 青岛 266520)
                摘   要: 水润滑轴承的轴瓦结构设计对其摩擦磨损和润滑性能有着重要影响. 为提升其摩擦学性能，设计一种轴瓦
                布置有仿生猪笼草结构的水润滑轴承，主要为蜡质区的月牙形结构和唇部的径向脊形结构两类. 利用ANSYS
                Fluent对简化后的轴承润滑水膜模型进行流场分析，改变不同转速、载荷和不同织构形状、尺寸，探究水膜承载能力
                和减摩性能的优化情况并进行机理分析. 结果表明：通过比较不同织构形状、尺寸下的轴承水膜最大压力与摩擦系
                数，发现型号CC1006的月牙形织构和型号DR0102的径向脊形织构的水膜承载能力和减摩性能综合优化最佳. 通过
                改变不同载荷，发现轴瓦布置有仿生猪笼草结构的水润滑轴承更适合应用于中速中载的条件下，此时其拥有优异
                的水膜承载能力与减摩性能. 该研究为仿生表面结构的水润滑轴承设计及摩擦学性能提升等提供了分析方法和理
                论依据.
                关键词: 仿生表面织构; 猪笼草; 水润滑轴承; 摩擦学性能; 有限元分析
                中图分类号: TH117.1                  文献标志码: A                   文章编号: 1004-0595(2021)03–0344–13


                    Finite Element Analysis of Tribological Properties of Bionic
                   Water-Lubricated Bearings with Nepenthes Alata Structures



                                         1,2              1,2*              1,2         1,2
                                LI Yunkai , WANG Youqiang , JIAN Guangxiao , LUO Heng
                            (1. School of Mechanical and Automotive Engineering, Qingdao University of Technology,
                                                Shandong Qingdao 266520, China
                         2. Key Lab of Industrial Fluid Energy Conservation and Pollution Control, Ministry of Education,
                                                Shandong Qingdao 266520, China)
                 Abstract: The structure design of water-lubricated bearings has a significant influence on their friction and wear
                 performances, as well as lubricity. A new type of bionic water-lubricated bearing has been designed in order to improve
                 its tribological properties. There were Nepenthes Alata structures on its bearing bush, which were mainly two types:
                 crescent textures on the surface of slippery zones and ridged textures on that of the peristome. The flow field analysis
                 was carried out by ANSYS Fluent used the simplified lubricating film model of the bearing. By the variation of
                 rotational speeds, loads and surface textures of different shapes and sizes, the optimization of the anti-friction
                 performance and the load-bearing capacity of water film were explored and the mechanism was analyzed. It was found
                 that the crescent texture of CC1006 and the ridged texture of DR0102 had the best comprehensive optimization of anti-
                 friction performance and load-bearing capacity of water film respectively by comparing the maximum pressure and load-


            Received 16 June 2020, revised 26 July 2020, accepted 6 September 2020, available online 28 May 2021.
            *Corresponding author. E-mail: wyq@qut.edu.cn, Tel: +86-18660279607.
            The project was supported by the Natural Science Foundation of China (51575289) and Shandong Key Research and Development
            Project (2019GHY112068).
            国家自然科学基金项目(51575289)和山东省重点研发计划项目(2019GHY112068)资助.
