第 40 卷 第 3 期 摩 擦 学 学 报 Vol 40 No 3
2020 年 5 月 Tribology May, 2020

DOI: 10.16078/j.tribology.2019199

690合金传热管在不同摩擦副条件下的

微动磨损性能研究

1
2*
1
米 雪 , 谢 海 , 彭金方 , 朱旻昊 2*
(1. 中国核动力研究设计院 核反应堆系统设计技术重点实验室，四川 成都 610213;
2. 西南交通大学 材料科学与工程学院，四川 成都 610031)
摘 要: 采用MFF-3000电磁振动微动疲劳与磨损试验机，研究两种抗振条材料(退火405不锈钢和淬火回火
06Cr13)对690合金传热管的微动磨损性能的影响，试验采用块/管线接触方式，即线接触. 试验结束后，采用OM、
SEM、EDX和EPMA和三维光学显微镜对磨痕微观形貌和成分等进行分析，对比分析两种摩擦副的微动摩擦行为.
结果表明：当配副材料为405不锈钢时，690合金的磨损相对严重；工况相同时，06Cr13的磨损比405不锈钢严重，且
405不锈钢的磨屑尺寸较小，06Cr13磨痕表面存在大量的剥层裂纹. 随着温度增加，磨屑增加，氧化程度加剧，磨损
加剧，主要的磨损机制为磨粒磨损和剥层.
关键词: 微动磨损; 690合金; 405不锈钢; 06Cr13; 管/块接触
中图分类号: TH117.3 文献标志码: A 文章编号: 1004-0595(2020)03–0314–08

Effect of Mating Material on Fretting Wear
Behavior of 690 Alloy

1 1 2* 2*
MI Xue , XIE Hai , PENG Jinfang , ZHU Minhao

(1. Science and Technology on Reactor System Design Technology Laboratory, Nuclear Power
Institute of China, Sichuan Chengdu 610213, China
2. School of Materials Science and Engineering, Southwest Jiaotong University, Sichuan Chengdu 610031, China)
Abstract: Fretting wear tests of 690 alloy against two anti-vibration bar materials (annealed 405 stainless steel and
quench-tempering 06Cr13) have been carried out using a fretting wear test rig (MFF-3000) with a contact configuration
of tube-on-plate. After tests, the worn surfaces and cross-sections were examined through optical microscope, scanning
electron microscopy, energy dispersive X-ray, electron probe microanalysis and a 3D optical microscope in order to
obtain information of morphology and surface chemical composition. The results indicated that the damage of 690 alloy
was severe when the contacting material was annealed 405 stainless steel. Under the same experimental condition, the
damage of quench-tempering 06Cr13 anti-vibration bar was worse than that of annealed 405 stainless steel. The wear
particles of annealed 405 stainless steel was smaller than that of quench-tempering 06Cr13. Meanwhile, numerous
delamination cracks were observed on worn surfaces of quench-tempering 06Cr13. In general, with increasing
temperature, more wear particles and higher level of oxygen content were observed. The most severe damage was
obtained at 90 ℃ and oscillation amplitude of 100 μm. The main wear mechanisms were delamination and abrasive
wear.
Key words: fretting wear; 690 alloy; 405 stainless steel; 06Cr13; tube-on-plate

Received 23 October 2019, revised 29 December 2019, accepted 30 December 2019, available online 28 May 2020.
*Corresponding author. E-mail: pengjinfang@swjtu.edu.cn, Tel: +86-13548043069; E-mail: zhuminhao@swjtu.cn, Tel: +86-28-
87600715.
The work was supported by the National Natural Science Foundation of China (U1534209, 51305364).
国家自然科学基金项目(U1534209, 51305364)资助.
