80

10 μm-40 Hz 参 考 文 献
60 15 μm-40 Hz
40 20 μm-40 Hz [ 1 ] Barnett M A, Silver A. Application of air bearings to high-speed
turbomachinery[C]//SAE International Farm, Construction, Industrial
20 Machinery and Powerplant Meetings, Milwaukee, 1970. doi:10.4271/
Force/N 0 700720.
−20
[ 2 ] Agrawal G L. Foil air/gas bearing technology-an overview[C]//
−40
ASME 1997 International Gas Turbine and Aeroengine Congress
−60
and Exhibition, Florida, 1997, 1: Aircraft Engine; Marine;
−80
−25 −20 −15 −10 −5 0 5 10 15 20 25 Turbomachinery; Microturbines and Small Turbomachinery. doi:
Displacement/μm
10.1115/97-GT-347.
Fig. 17 Effect of different amplitudes on dynamic [ 3 ] Le Lez S, Arghir M, Frêne J. Nonlinear numerical prediction of gas
hysteresis curve foil bearing stability and unbalanced response[J]. Journal of
图 17 不同振幅对动态回滞曲线的影响 Engineering for Gas Turbines and Power, 2009, 131(1): 012503. doi:

10.1115/1.2967481.

80 [ 4 ] Liu Zhansheng, Xu Huaijin. Application and research progress of
0 N-10 μm
60 30 N-10 μm bump-type foil aerodynamic journal bearings[J]. Bearing, 2008, (1):
40 50 N-10 μm 39–43 (in Chinese) [刘占生, 许怀锦. 波箔型动压气体径向轴承的
20 应 用 与 研 究 进 展 [J]. 轴 承 , 2008, (1): 39–43]. doi: 10.19533/j.
Force/N −20 0 [ 5 ] issn1000-3762.2008.01.013.
Liu Jiaqi, Bi Chunxiao, Han Dongjiang, et al. Research progress of
−40 elastic foil bearings[J]. Lubrication Engineering, 2022, 47(9):
−60 166–178 (in Chinese) [刘佳琦, 毕春晓, 韩东江, 等. 弹性箔片轴承
−80 的研究进展[J]. 润滑与密封, 2022, 47(9): 166–178]. doi: 10.3969/j.
−15 −10 −5 0 5 10 15
Displacement/μm issn.0254-0150.2022.09.025.
[ 6 ] Agrawal G L. Foil air bearings cleared to land[J]. Mechanical
Fig. 18 Effect of different preload forces on dynamic
Engineering, 1998, 120(7): 78–80. doi: 10.1115/1.1998-jul-8.
hysteresis curve
图 18 不同预紧力对动态回滞曲线的影响 [ 7 ] Heshmat H, Walowit J A, Pinkus O. Analysis of gas-lubricated foil
journal bearings[J]. Journal of Lubrication Technology, 1983,
关系，回滞曲线有一定面积，表明存在一定的能量耗散. 105(4): 647–655. doi: 10.1115/1.3254697.
动态特性试验分通过时域和频域2种方法进行计算， [ 8 ] Ku C P R, Heshmat H. Compliant foil bearing structural stiffness
analysis —part II: experimental investigation[J]. Journal of
验证了计算公式应用在多叶型空气箔片轴承的可靠性.
Tribology, 1993, 115(3): 364–369. doi: 10.1115/1.2921644.
b. 动态试验表明频率对刚度和回滞曲线面积影
[ 9 ] Heshmat H, Ku C P R. Structural damping of self-acting compliant
响不大，频率越大，阻尼越小. 振幅越大，轴承刚度和 foil journal bearings[J]. Journal of Tribology, 1994, 116(1): 76–82.
阻尼越小，回滞曲线面积越大. 外部预紧力越大，轴承 doi: 10.1115/1.2927050.
刚度、阻尼和回滞曲线面积越大，这可能与不同工况 [10] Dellacorte C, Valco M J. Load capacity estimation of foil air journal
bearings for oil-free turbomachinery applications[J]. Tribology Tran-
下轴承内有效波箔数量有关.
sactions, 2000, 43(4): 795–801. doi: 10.1080/10402000008982410.
此外，除了频率、振幅和预紧力对轴承动态特性
[11] Rubio D, San Andrés L. Bump-type foil bearing structural stiffness:
的影响外，加载点的位置、转子与顶箔的间隙以及温
experiments and predictions[J]. Journal of Engineering for Gas
度都会对轴承的性能产生影响. 试验中都是对趋于每 Turbines & Power, 2006, 128(3): 653–660. doi: 10.1115/1.2056047.
片箔片的中心位置进行加载，由于多叶型空气箔片轴 [12] San Andrés L, Chirathadam T A, Kim T H. Measurement of
承采用5片箔片搭接的结构，每一片箔片的周向距离 structural stiffness and damping coefficients in a metal mesh foil
bearing[J]. Journal of Engineering for Gas Turbines and Power,
较小，也可在每片箔片的不同位置进行加载. 改变轴
2010, 132(3): 032503. doi: 10.1115/1.3159379.
径的大小可以改变初始装配的间隙，这对轴承的性能
[13] San Andrés L, Ryu K, Kim T H. Identification of structural stiffness
也会有影响. 最后由于转子不转，可以通过加热转子 and energy dissipation parameters in a second generation foil
来改变工况的温度，从而探究温度对轴承性能的影响. bearing: effect of shaft temperature[J]. Journal of Engineering for
