               Fig. 11  The cross-section morphologies of worn 690 alloy，D=100 μm，T=90 ℃，690 alloy/06Cr13
                        图 11    690合金的剖面分析结果，D=100 μm，T=90 ℃，配副材料06Cr13

   致. 总体而言，690合金磨损不严重.                                    发生器传热管的微振磨损及其防护[J]. 核安全, 2006, (3): 27–32].
                                                          doi: 10.16432/j.cnki.1672-5360.2006.03.007.
   3    结论                                           [  5  ]  Ding  Xunshen.  The  design  safety  of  steam  generators  in  NPP[J].
                                                          Nuclear Safe, 2005, (2): 1–6 (in Chinese) [丁训慎. 核电厂蒸汽发生
       a. 随着温度和位移的增加，690合金表面的磨屑
                                                          器设计中的安全问题[J]. 核安全, 2005, (2): 1–6]. doi: 10.16432/
   增加，氧化程度加剧，磨损加剧；主要的磨损机制为磨
                                                          j.cnki.1672-5360.2005.02.001.
   粒磨损和剥层，且随着温度的增加，剥层在损伤中所
                                                     [  6  ]  Tang Hui. Fretting damage one of world-wide difficulties in the field
   起的作用加剧. 由于水的作用，690合金的磨损轻微，                             of  nuclear  power  equipment  and  structures  for  a  long-term[J].
   其剖面未见裂纹和磨屑层.                                           Nuclear Power Engineering, 2000, 21(3): 221–231 (in Chinese) [唐
       b. 当配副材料为405不锈钢时，690合金的磨损较                         辉. 世界核电设备与结构将长期面临的一个问题—微动损伤[J].
   严重. 这可能是由于工况相同时，06Cr13的磨损比                             核 动 力 工 程 ,  2000,  21(3):  221 –231].  doi:  10.3969/j.issn.0258-
   405不锈钢严重，06Cr13形成大量磨屑，起固体润滑和                           0926.2000.03.008.
                                                     [  7  ]  Zhang  Xiaoyu,  Ren  Pingdi,  Zhang  Yafei,  et  al.  Fretting  wear
   承重的作用，减少690合金的磨损. 此外，405不锈钢的
                                                          behavior of Incoloy 800 alloy at high temperature[J]. The Chinese
   磨屑尺寸较小，06Cr13磨痕表面存在大量的剥层裂纹.
                                                          Journal of Nonferrous Metals, 2010, 20(8): 1545–1551 (in Chinese)
       c. 磨痕表面的化学成分分析表明，06Cr13表面的                         [张晓宇, 任平弟, 张亚非, 等. Incoloy800 合金的高温微动磨损特
   材料在剥落之前，由于相对运动已被氧化；690合金的                              性[J]. 中国有色金属学报, 2010, 20(8): 1545–1551]. doi: 10.19476/
   EPMA线扫描结果表明，在磨损区域中氧和铁的含量                               j.ysxb.1004.0609.2010.08.016.
   变化呈现锯齿状；黏着磨损致使的材料转移，690合金                         [  8  ]  Zheng Jinsong, Zhao Lina, Li Gan. The effect of contact force and
   表面有贫镍区.                                                temperature  on  the  fatigue  life  of  Inconel  690  alloy[J].  Materials
                                                          Protection, 2015, 48(3): 27–30 (in Chinese) [郑劲松, 赵丽娜, 厉淦.
