第 40 卷 第 5 期 摩 擦 学 学 报 Vol 40 No 5
2020 年 9 月 Tribology Sept, 2020

DOI: 10.16078/j.tribology.2019236

球形摩擦纳米波浪能发电机的多物理场

耦合建模方法研究

赵 波, 董树林, 李自豪, 张保成 *
(中国海洋大学工程学院 机电工程系，山东 青岛 266000)

摘 要: 球形摩擦纳米发电机因其对低频、高随机性的波浪能具有优异的捕获性能，日益受到波浪能研究者的青睐.
为了实现对其在特定波况条件下发电性能的定量研究，基于COMSOL Multiphysics多物理场仿真软件，本文作者提
出了一种针对球形摩擦纳米波浪能发电机的高保真多物理场耦合建模方法. 该模型可以兼顾准确性和高效性地模
拟球形摩擦纳米发电机在特定波况下的多物理场耦合作用及电能输出情况，是对当前国内外普遍采用的基于静电
场的静态仿真方法的发展和改进. 基于该方法，本研究针对四电极型的球形摩擦发电机进行了建模和性能研究，实
现了从推板造波到电能输出的全过程、高保真、实时、定量仿真，为对其开展结构优化设计并最终走向实用化提供
了一种有效手段.
关键词: 波浪能; 球形摩擦纳米发电机; COMSOL; 高保真仿真; 多物理场耦合
中图分类号: TH117.3 文献标志码: A 文章编号: 1004-0595(2020)05–0680–07

Multi-Physics Coupling Modeling Method for the Rolling-
Spherical Triboelectric Nanogenerator

ZHAO Bo, DONG Shulin, LI Zihao, ZHANG Baocheng *

(Department of mechatronic Engineering, College of Engineering, Ocean University of China,
Shandong Qingdao 266000, China)
Abstract: Rolling-spherical triboelectric nanogenerator (R-TENG) are increasingly favored by wave energy researchers
because of their excellent work performance for low frequency, highly random wave energy. To realize the quantitative
research on the performance of R-TENG under specific wave conditions, this paper proposed a high-fidelity and multi-
physics coupling modeling method for R-TENG based on COMSOL Multiphysics simulation software. By using the
model, the multi-physics coupling effect and power output of R-TENG under specific wave conditions can be accurately
and efficiently simulated. This model can be regarded as the development and improvement of static simulation methods
based on electrostatic field commonly used at home and abroad. Based on this method, this model investigated the
modeling and performance of a four-electrode R-TENG, and provided the high-precision, real-time and quantitative
simulation of the whole process from the wave-making to the power output. This made it possible to carry out the
structural optimization design and finally to provide effective means to manufacture.
Key words: wave energy; rolling-spherical triboelectric nanogenerator; COMSOL; simulation of high-fidelity; coupling
of multi-physics

Received 26 September 2019, revised 18 February 2020, accepted 28 February 2020, available online 28 September 2020.
*Corresponding author. E-mail: zbc2014088@ouc.edu.cn, Tel: +86-17854287810.
The project was supported by the National Natural Science Foundation of China (51909254), Fundamental Research Funds for the
Central Universities (201965006, 201912006) and Qingdao Pioneering and Innovation Leading Talents Program (18-1-2-20-zhc).
国家自然科学基金项目(51909254)，中央高校基础研究基金（201965006, 201912006）和青岛市创业创新领军人才计划项目(18-
1-2-20-zhc)资助.
