陈 阳等：硅尖锥冷阴极阵列衬底供应电流一致化排布设计 359

electron emission from Si tip with ultra-thin diamond like sics Letters，2006，89：233518.
carbon coating [C]// Brno：The Technical Digest of 37th In- [9] DING M，SHA G，AKINWANDE A. Silicon field emission
ternational Vacuum Nanoelectronics Conference （IVNC）， arrays with atomically sharp tips：Turn-on voltage and the ef-
2024. fect of tip radius distribution[J]. IEEE Transactions on Elec-
[2] HUANG J， HUANG Y， ZENG M， et al. Fabrication of tron Devices，2002，49（12）：2333−2342.
Spindt-type nanometer-sized chromium tips for application as [10] HUANG Y，HUANG Z，SHE J，et al. Quasi-saturated ar-
field-electron emitters by releasing the stress of the deposited senic concentration and uniform electron emission by regu-
thin film[J]. ACS Applied Nano Materials，2023，6（1）：351− lating thermal oxidation of Si nanotips[J]. IEEE Transac-
357. tions on Electron Devices，2019，66（3）：1545−1551.
[3] WANG Z，HUANG Y，CHEN Y，et al. On-chip integrated Si- [11] HUANG Z，HUANG Y，PAN Z，et al. Self-modulated field
tip field electron emission vacuum transistor with saturated electron emitter：Gated device of integrated Si tip-on-nano-
output characteristics [C]//Brno：The Technical Digest of 37th
channel[J]. Applied Physics Letter，2016，109（23）：233501.
International Vacuum Nanoelectronics Conference （IVNC），
[12] ZENG M，HUANG Y，HUANG J，et al. Gated Si-tip with
2024.
on-tip integrated gate-all-around field effect transistor for
[4] WANG C， ZHANG G， LIU Q， et al. Fabrication of ZnO
actively controlled field electron emission[J]. IEEE Elec-
nanowire cold cathode flat-panel X-ray source with a reflec-
tron Device Letters，2022，43（3）：466−469.
tive anode[J]. Nanomaterials，2024，14（18）：1504.
[13] SAWADA K，JI K，ANDO T，et al. Characterization of p-
[5] 陈阳，章易，黄一峰，等. 硅微尖锥冷阴极微加工及其场发
type silicon field emitters[J]. Japanese Journal of Applied
射器件物理 [J]. 真空电子技术，2022（6）：23−28.
Physics，1994，33（9）：L1345.
[6] HAUSLADEN M， SCHELS A， BUCHNER P， et al. Mea-
[14] HUANG Y，CHEN Y，HUANG Z，et al. P-type Si-tips with
surement of field emission array current distributions by met-
integrated nanochannels for stable nonsaturated high cur-
al-coated CMOS image sensors[J]. Journal of Vacuum Sci-
rent density field electron emission[J]. IEEE Transactions
ence and Technology B，2024，42：062209.
on Electron Devices，2022，69（7）：3908−3913.
[7] HUANG Y，DENG Z，WANG W，et al. Field-induced crys-
[15] CHEN Y，HUANG Y，WEI Y，et al. Uniform current sup-
talline-to-amorphous phase transformation on the Si nano-apex
ply in gated p-type Si-tips for achieving high-performance
and the achieving of highly reliable Si nano-cathodes[J]. Sci-
field electron emitter array[J]. IEEE Transactions on Elec-
entific Reports，2015，5：10631.
tron Devices，2024，71（8）：5034−5039.
[8] SHE J，HE H，XU N，et al. Arrays of vacuum microdiodes
using uniform diamondlike-carbon tip apexes[J]. Applied Phy- （责任编辑：郭 云）

引文信息：陈阳，黄一峰，佘峻聪. 硅尖锥冷阴极阵列衬底供应电流一致化排布设计[J]. 真空与低温，2025，31（3）：354−359.
CHEN Y，HUANG Y F，SHE J C. Arrangement design of Si-tip field emitter array for uniform current supply from the sub-
strate[J]. Vacuum and Cryogenics，2025，31（3）：354−359.
