图 8 模型评估原理图
Fig. 8 Schematic diagram of model evaluation

表 3 模型的计算结果统计
Table 3 Statistics of calculation results of the model
D/mm H/mm δ/mm v p/GPa a 11 a 21 a 22 a p a 3 a 响应等级
5 13 0.5 0.65 0.2 0.03 0.63 0.09 0.2 0.165 Ⅰ
0 5 5 0.3 0.71 0.2 0.2 0.2 0.1 0.2 0.2 Ⅱ
3.5 13 0.5 0.85 0.61 0.03 0.63 0.21 0.2 0.234 80%Ⅲ
5 13 0.3 0.56 0.2 0.03 0.2 0.07 0.22 0.154 Ⅰ
5 3.5 25 0.5 0.62 0.61 0.01 0.63 0.22 0.22 0.204 Ⅱ
5 5 0.5 0.83 0.2 0.2 0.63 0.12 0.22 0.239 92%Ⅲ
3.5 25 0.3 0.53 0.61 0.01 0.2 0.20 0.316 0.189 Ⅰ
8 5 13 0.3 0.55 0.2 0.03 0.2 0.07 0.316 0.201 Ⅱ
5 13 0.5 0.65 0.2 0.03 0.63 0.09 0.316 0.22 47%Ⅲ
5 25 0.3 0.32 0.2 0.01 0.2 0.07 0.325 0.185 Ⅰ
5 25 0.5 0.47 0.2 0.01 0.63 0.09 0.325 0.205 Ⅱ
10 3.5 5 0.3 0.93 0.61 0.2 0.2 0.22 0.325 0.267 100%Ⅲ
2 5 0.3 1.56 0.72 0.2 0.2 0.26 0.325 0.301 Ⅳ
2 5 0.5 1.66 0.85 0.2 0.63 0.28 0.325 0.32 40%Ⅴ
5 50 0.3 0.21 0.2 0.06 0.2 0.08 0.33 0.188 Ⅰ
5 25 0.3 0.33 0.2 0.01 0.2 0.07 0.33 0.199 Ⅱ
11 3.5 5 0.5 1.07 0.61 0.2 0.63 0.22 0.33 0.241 97%Ⅲ
2 13 0.3 1.33 0.61 0.03 0.2 0.20 0.33 0.298 Ⅳ
2 13 0.5 1.45 0.72 0.03 0.63 0.25 0.33 0.316 32%Ⅴ
5 50 0.3 0.21 0.2 0.006 0.2 0.08 0.332 0.185 Ⅰ
5 50 0.5 0.26 0.2 0.006 0.63 0.09 0.332 0.202 Ⅱ
12 3.5 5 0.5 1.07 0.61 0.2 0.63 0.24 0.332 0.242 99%Ⅲ
2 25 0.5 1.25 0.72 0.01 0.63 0.25 0.332 0.297 Ⅳ
2 13 0.5 1.45 0.72 0.03 0.63 0.25 0.332 0.322 44%Ⅴ
注：v 为波形调整器材料泊松比，p 为冲击过载压力，Ⅰ表示未反应，Ⅱ表示开始燃烧，Ⅲ表示发生燃烧反应，Ⅳ表示开始爆燃，Ⅴ表示
发生爆燃反应，百分比表示响应程度。
