第 45 卷 第 5 期 爆 炸 与 冲 击 Vol. 45, No. 5
2025 年 5 月 EXPLOSION AND SHOCK WAVES May, 2025

DOI：10.11883/bzycj-2024-0121

装置参数对 125 kg 燃料成雾性能的影响 *

王 晔 ，白春华 ，刘文杰 3
1
2
（1. 华北科技学院研究生部，河北 廊坊 065201；
2. 北京理工大学爆炸科学与技术国家重点实验室，北京 100081；
3. 中北大学环境与安全工程学院，山西 太原 030051）

摘要： 云雾的起爆状态决定爆轰威力，装置结构和比药量是影响云雾形态的主要因素。基于装置结构与云雾形
状相似性的原理，对 125 kg 云雾的成雾性能进行试验研究，利用高速摄像进行全过程记录，获取了不同轴向强度装置
结构和比药量对云雾特征的影响规律。结果表明：大体积燃料抛撒试验的成雾稳定性较好；轴向约束强的复合结构形
成的云雾直径具有优势，相同比药量下，复合结构的云雾直径可以达到 25.5 m，较强结构的云雾覆盖面积增加 13%；比
药量为 0.8% 时，复合结构燃料的成雾性能最佳，125 kg 燃料的 2 次起爆延迟时间为 240 ms，此时，云雾瞬时计算浓度为
3
64 g/m ，当量比为 0.54。
关键词： 云雾形成；爆炸抛撒；装置结构；比药量
中图分类号： O383; TJ55 国标学科代码： 13035 文献标志码： A

Influence of structural parameters on formation
characteristics of 125 kg FAE clouds

1
2
WANG Ye , BAI Chunhua , LIU Wenjie 3
（1. Graduate Department, North China Institute of Science and Technology, Langfang 065201, Hebei, China;
2. State Key Laboratory of Explosion Science and Technology, Beijing Institute of Technology, Beijing 100081, China;
3. School of Environmental and Safety Engineering, North University of China, Taiyuan 030051, Shanxi, China）

Abstract: The large-scale explosive dispersal and the unconfined detonation of particle-spray-air ternary mixtures are closely
related to industrial accidents and military applications. However, most of the existing research focuses on the small-scale
experiment in the laboratory, with large-scale explosive dispersal experiments being relatively scarce. The initiation state of the
aerosol cloud determines the blast power, and the device structure and specific explosive charge are the main factors affecting
the cloud morphology. To study the damaging effect of aerosol, the large-scale dispersed experiment of 125 kg fuel was carried
out. The process of aerosol development was observed by high-speed video recording. Variation characteristics of FAE cloud
with different canisters and the specific central explosive were studied. The aerosol diameter and height were used to
describing the aerosol shape, then they were analyzed under different initial experiment conditions. Three types of canisters
were utilized, namely the basic canister, the compound canister, and the strengthen canister, with the primary difference being
their radial restraint mechanisms. The specific central explosive was adopted the T-shaped charge. The results show that the
aerosol formation is reliable through the replication experiments. Because of its strong radial restraint, the compound canister

has the advantage in the aerosol diameters. The aerosol diameters of compound canister can reach 25.5 m, compared to strong

* 收稿日期： 2024-04-30；修回日期： 2024-12-17
基金项目： 国家自然科学基金（42377200）；中央高校基本科研业务费专项资金（3142019011）；廊坊市科学技术研究与发
展计划自筹经费项目（2018013101）
第一作者： 王 晔（1986－ ），女，博士，讲师，wangye_0422@126.com

052301-1
