蔡胜民, 胡杨, 丁鹏静. 多叶型空气箔片轴承静动特性试验研究[J]. 摩擦学学报（中英文）, 2025, 45(5): 637−646. CAI
Shengmin, HU Yang, DING Pengjing. Experimental Study on Static and Dynamic Characteristics of Multi-leaf Air Foil Bearings[J].
Tribology, 2025, 45(5): 637−646.

多叶型空气箔片轴承静动特性试验研究

*
蔡胜民, 胡 杨 , 丁鹏静
(上海大学 机电工程与自动化学院 上海市智能制造与机器人重点实验室，上海 200444)

摘 要: 气体箔片轴承因其具有高转速、无污染且运行寿命长等特点具有广泛应用，如今的气体箔片轴承发展到第
4代多叶型空气箔片轴承. 多叶型空气箔片轴承因其顶箔的相互搭接产生预紧力，波箔提供弹性支撑，配合表面涂
层使其具有良好的特性. 分别搭建静态特性和动态特性试验台，对多叶型空气箔片轴承的静态特性和动态特性进
行了试验研究. 静态特性试验通过分析多叶型空气箔片轴承的静态加载力与位移回滞曲线，得到轴承的刚度特性，
动态特性试验通过时域和频域分析2种方法得到轴承的刚度和阻尼特性，此外研究了不同频率、振幅和预紧力对多
叶型空气箔片轴承动态特性以及动态加载力与位移的回滞曲线影响. 试验结果表明：静态特性试验时，静态加载力
与位移回滞曲线并不重合，静态刚度随位移的增大而增大，并呈非线性分布，在推拉加载到最大载荷时反转加载方
向，刚度也会突变；动态特性试验时，时域和频域2种方法得到的轴承刚度和阻尼特性相近，证明数据处理方法的准
确性. 频率对刚度和回滞曲线影响不大，频率越大，阻尼越小，频率对阻尼的影响最明显；振幅越大，轴承动态特性
越小，回滞曲线越大；外部预紧力越大，轴承动态特性和回滞曲线都越大，振幅和外部预紧力对轴承刚度和阻尼以
及回滞曲线都有一定影响. 所提出的试验数据可以提供有价值的参考.
关键词: 多叶型空气箔片轴承; 静态特性; 动态特性; 非线性; 回滞曲线
中图分类号: TH133.36 文献标志码: A 文章编号: 1004-0595(2025)05–0637–10

Experimental Study on Static and Dynamic Characteristics of

Multi-leaf Air Foil Bearings

*
CAI Shengmin, HU Yang , DING Pengjing

(Shanghai Key Laboratory of Intelligent Manufacturing and Robotics, School of Mechanical and Electrical Engineering
and Automation, Shanghai University, Shanghai 200444, China)
Abstract: Gas foil bearings are widely used because of their high speed, no pollution, and long operating life. Today’s
gas foil bearings have developed into the fourth generation multi-leaf air foil bearings. Multi-leaf air foil bearings have
good characteristics due to the mutual overlap of the top foils to generate preload force, the bump foil provides elastic
support, and combined with the surface coating. This paper studied the static and dynamic characteristics of multi-leaf
air foil bearings through experimental methods, static characteristics and dynamic characteristics experimental benches
were designed and built, respectively. The static characteristics experiment analyzed the static loading force and
displacement hysteresis curves of the multi-leaf air foil bearing to obtain the stiffness characteristics of the bearing. The
dynamic characteristics experiment obtained the stiffness and damping characteristics of the bearing through two
methods: time domain and frequency domain analysis. In addition, the effects of different frequencies, different

Received 3 January 2024, revised 3 April 2024, accepted 7 April 2024, available online 1 July 2024.
*Corresponding author. E-mail: huyang0330@shu.edu.cn, Tel: +86-15121170010.
This project was supported by the National Natural Science Foundation of China (52275204, 51905298).
国家自然科学基金项目(52275204, 51905298)资助.
