第 41 卷 第 1 期 摩 擦 学 学 报 Vol 41 No 1
2021 年 1 月 Tribology Jan, 2021

DOI: 10.16078/j.tribology.2020051

新型TBM刀圈材料微观组织及耐磨性能研究

2
1
2
1*
1
1
蒋金哲 , 王 锴 , 郭 浩 , 白岩凌 , 张峻嘉 , 刘 越 , 刘春明 1
(1. 东北大学 材料科学与工程学院，辽宁 沈阳 110819;
2. 中铁工程装备集团 隧道设备制造有限公司，河南 新乡 453011)
摘 要: TBM刀圈材料是一种对强韧性、耐磨性要求很高的合金钢材料. 目前常用的H13、DC53型TBM刀圈材料综
合性能有待提高. 通过优化合金元素配比，制备出一种强韧型综合性能较好的新型TBM刀圈材料DB1，利用光学显
微镜和扫描电子显微镜对DB1、H13和DC53的微观组织及断口形貌进行了观察分析，研究了不同载荷和不同硬度
岩石条件下DB1与H13、DC53的磨损性能的差异，并对其磨损表面形貌进行扫描电子显微镜观察分析. 结果表明：
一次碳化物的平均尺寸和含量对TBM刀圈材料的硬度、韧性及耐磨性有重要影响；适量的一次碳化物有助于提高
材料的硬度及耐磨性；过多的一次碳化物会导致材料韧性急剧下降. 岩石抗压强度与刀圈具有匹配性，新型TBM刀
圈材料DB1钢用于中等抗压强度的岩石时具有较好的耐磨性.
关键词: TBM刀圈; 硬度; 韧性; 碳化物; 磨损量; 磨损形貌
中图分类号: U455.3 文献标志码: A 文章编号: 1004-0595(2021)01–0017–10

Microstructure and Wear Resistance of Novel TBM

Cutter Ring Steel

1 2 2 1 1 1* 1
JIANG Jinzhe , WANG Kai , GUO Hao , BAI Yanling , ZHANG Junjia , LIU Yue , LIU Chunming
(1. School of Materials Science and Engineering, Northeastern University, Liaoning Shenyang 110819, China
2. Tunnel Equipment Manufacturing Co Ltd, China Railway Engineering Equipment Group,
Henan Xinxiang 453011, China)
Abstract: TBM cutter ring is an alloy steel required a high level of strength, toughness and abrasion resistance. The
comprehensive performances of H13 and DC53 cutter ring steels need improving. In this paper, a novel TBM cutter ring
steel DB1 with better strength and toughness was developed by optimizing the concentration of alloying element. The
microstructure and fracture morphology of DB1, H13 and DC53 steel were studied via scanning electron microscope.
The wear properties of DB1, H13 and DC53 under different loads and different hardness of rock were studied via wear
testing machine, and the wear surface morphology was studied by scanning electron microscope. The results showed that
the size and content of primary carbides had important effects on the hardness and toughness of TBM cutter ring
material. Proper amount of primary carbide was helpful to improve the hardness and wear resistance of cutter ring
material. Excess primary carbide led to a sharp decrease in the toughness. There was a matching behavior between TBM
cutter ring and rocks with different compressive strengths. DB1 steel had better wear resistance in cutting rock with
moderate compressive strength.
Key words: TBM cutter ring; hardness; toughness; carbide; wear loss; wear morphology

硬岩隧道掘进机(Tunnel Boring Machine，TBM) 路、水电和矿山等岩石隧洞建设 [1-3] . TBM刀圈是TBM
是一种用于岩石隧道挖掘的大型专用机器，具有掘进 掘进过程中最直接与岩石接触的部件，在TBM驱动作

效率高、利于环保、综合效益高等优点，广泛应用于铁 用下，刀圈在岩面上连续滚动以碾压和破碎岩石. TBM

Received 31 March 2020, revised 5 June 2020, accepted 9 June 2020, available online 28 January 2021.
*Corresponding author. E-mail: dbdx555@163.com, Tel: +86-13940062930.
