第 32 卷 第 1 期 真空与低温
2026 年 1 月 Vacuum and Cryogenics 17
立 方 形 真 空 容 器 壁 厚 设 计 校 核 与 透 射 界 面 设 计
3
苏玉磊 1,3,4 ，陈建徽 ，黄 倩 1,3* ，胡志勇 ，张 振 3,4 ，丁怀况 1,3,4 ，章学华 1,3,4
2
（1. 中国电子科技集团公司第十六研究所，合肥 230088；
2. 大连理工大学，辽宁 盘锦 124221；3. 安徽万瑞冷电科技有限公司，合肥 230088；
4. 安徽省低温与真空工程研究中心，合肥 230088）
摘要：针对真空环境下激光与材料相互作用研究的光学平台对观测环境高稳定性的需求，提出一种基于非圆
形截面容器设计理论的立方形真空容器设计方案。依据 GB/T 150.3—2024 进行结构设计，并通过三维有限元仿
真验证，系统解析外压载荷下拐角区域的三维不连续应力传递机制。采用亚克力-金属复合观察窗设计，结合材料
蠕变特性与密封界面变形协调准则进行参数优化。通过多壁厚方案的成本评估，揭示成本非线性增长对制造成
本的影响；针对拐角应力集中现象，基于疲劳评估准则提出局部强化策略。该设计成功应用于激光驱动真空实验
平台，为特种光学观测设备提供了兼具结构稳定性、经济性与功能匹配性的设计范式。
关键词：立方形真空容器；有限元验证；真空技术；非圆形截面
中图分类号：TB71 文献标志码：A 文章编号：1006-7086（2026）01-0017-08
DOI：10.12446/j.issn.1006-7086.2026.01.002
Design Verification of Wall Thickness for Cubic Vacuum Containers and Transmission Interface Design
2
3,4
3
SU Yulei 1,3,4 ，CHEN Jianhui ，HUANG Qian 1,3* ，HU Zhiyong ，ZHANG Zhen ，DING Huaikuang 1,3,4 ，ZHANG Xuehua 1,3,4
（1. The 16th Research Institute of China Electronics Technology Group Corporation，Hefei 230088，China；
2. Dalian University of Technology，Panjin 124221，Liaoning，China；
3. Vacree Technologies Co.，Ltd.，Hefei 230088，China；
4. Cryogenics & Vacuum Engineering Research Center of Anhui Province，Hefei 230088，China）
Abstract：To address the critical demand for a highly stable observation environment in the study of laser-material inter-
actions under vacuum conditions，this paper proposes a novel cubic vacuum chamber design based on the theory of non-circu-
lar cross-section pressure vessels. Conventional cylindrical chambers，while structurally efficient，often impose constraints on
multi-axial optical access and system integration. This cubic design paradigm aims to better accommodate the geometric
and functional requirements of advanced optical experimental setups. The structural design of the cubic vessel was
conducted in strict compliance with the national pressure vessel code GB/T 150.3—2024. Its mechanical perfor-
mance was rigorously validated through three-dimensional finite element analysis （FEA） under simulated external pres-
sure loads. A key aspect of this simulation was the systematic investigation into the complex three-dimensional discontinuous
stress transfer and concentration mechanisms prevalent in the chamber's corner regions. This detailed analysis provided criti-
cal insights into stress hotspots that are often neglected by simplified analytical models，forming the foundation for targeted
structural enhancements. To ensure optical clarity and maintain vacuum integrity， an acrylic-metal composite observation
window was designed and integrated. The parameters of this window assembly were optimized through a comprehensive ap-
proach that accounted for the long-term creep behavior of the acrylic viewport under vacuum and the deformation compatibil-
ity criterion at the critical metal-to-acrylic sealing interface. This dual consideration guarantees both a reliable，durable seal
and minimal optical distortion throughout extended operational cycles. A parallel cost-benefit analysis of various wall-thick-
ness schemes for the main chamber body was performed. This study revealed a pronounced nonlinear relationship between
收稿日期：2025−09−02
基金项目：安徽省科技重大专项（18030901038）
作者简介：苏玉磊，高级工程师。E-mail：suyulei@vacree.com
通信作者：黄倩，工程师。E-mail：huangqian@vacree.com
